The SAIFERM steam generator uses well-known imported accessories, which are corrosion-resistant and finely crafted. Fast steam production in one minute, with a thermal efficiency of up to 100.27%. Clean steam, sufficient gas production, can provide stable steam for a long time, ensuring the required heat energy during the drying process. Advanced vertical cross flow structure, using 12Cr1MoVG high-pressure boiler steel and stainless steel laser fins with extremely high heat transfer efficiency, no explosion risk, safer equipment, and better steam quality.
Features
- Low nitrogen energy saving
The Tangyi steam generator adopts the latest fully premixed surface combustion technology. Before the gas combustion reaction occurs, the gas and all the air required for combustion are mixed evenly according to the optimal combustion value at once. After reaching the combustion zone, it can burn completely instantly with a combustion intensity of up to 2500KW/m ³. Imported metal fiber combustion heads are used for surface combustion. In addition to extremely high combustion efficiency, the surface combustion flame is small and evenly heated, basically eliminating extreme high temperatures in the combustion chamber. It can effectively suppress the production of nitrogen oxides, with emissions below 30mg/m ³, meeting the strict environmental requirements of the region. - Energy saving and cost saving
Due to its unique structure, the steam generator does not require preheating, saving you the additional cost loss caused by traditional boiler boosting and preheating. In addition, compared to the three-stage fire regulation control of traditional boilers, the steam generator adopts variable frequency control technology, which does not require shutdown or frequent start-up. Long term use can greatly reduce energy consumption. And the steam generator does not require a stoker, it can be activated with just one click and runs fully automatically. - High security
SAIFERM steam generators are equipped with various protections, including low water level protection, overtemperature protection, overpressure protection, gas pressure protection, mechanical emergency stop switch, etc., to ensure the safe and stable operation of the steam generator.
